3NP114 Fuse Switch-Disconnectors, Size 1
Fuse switch-disconnectors for size 1 NH fuse-links, plate or busbar mounting, with EFM fuse state signalling option. This series contains 66 references.
The list is taken from OEZ's current Varius catalogue; click a type code for technical data, dimension drawings and documents on the OEZ product page. Contact us for price and stock.
Fuse switch-disconnectors
| Type | Size | Poles | Signalling | Mounting | Busbar spacing |
|---|---|---|---|---|---|
| 3NP1141-1DA10 | 1 | 1 | – | Mounting plate | – |
| 3NP1141-1DA14 | 1 | 1 | EFM15 (AC 24–230 V/DC 24–250 V) | – | – |
| 3NP1141-1DA20 | 1 | 1 | – | Mounting plate | – |
| 3NP1141-1DA24 | 1 | 1 | EFM15 (AC 24–230 V/DC 24–250 V) | – | – |
| 3NP1143-1BC10 | 1 | 3 | – | Busbar | 60 mm |
| 3NP1143-1BC11 | 1 | 3 | MFM (AC 24–690 V/DC 24–440 V) | – | – |
| 3NP1143-1BC12 | 1 | 3 | EFM10 (AC 230–690 V) | Busbar | – |
| 3NP1143-1BC13 | 1 | 3 | EFM20 (AC 230–690 V) | Busbar | – |
| 3NP1143-1BC14 | 1 | 3 | EFM15 (AC 190–690 V) | Busbar | – |
| 3NP1143-1BC20 | 1 | 3 | – | Busbar | 60 mm |
| 3NP1143-1BC21 | 1 | 3 | MFM (AC 24–690 V/DC 24–440 V) | – | – |
| 3NP1143-1BC22 | 1 | 3 | EFM10 (AC 230–690 V) | Busbar | – |
| 3NP1143-1BC23 | 1 | 3 | EFM20 (AC 230–690 V) | Busbar | – |
| 3NP1143-1BC24 | 1 | 3 | EFM15 (AC 190–690 V) | Busbar | – |
| 3NP1143-1DA10 | 1 | 3 | – | Mounting plate | – |
| 3NP1143-1DA11 | 1 | 3 | MFM (AC 24–690 V/DC 24–440 V) | – | – |
| 3NP1143-1DA12 | 1 | 3 | EFM10 (AC 230–690 V) | Mounting plate | – |
| 3NP1143-1DA13 | 1 | 3 | EFM20 (AC 230–690 V) | Mounting plate | – |
| 3NP1143-1DA14 | 1 | 3 | EFM15 (AC 190–690 V) | Mounting plate | – |
| 3NP1143-1DA20 | 1 | 3 | – | Mounting plate | – |
| 3NP1143-1DA21 | 1 | 3 | MFM (AC 24–690 V/DC 24–440 V) | – | – |
| 3NP1143-1DA22 | 1 | 3 | EFM10 (AC 230–690 V) | Mounting plate | – |
| 3NP1143-1DA23 | 1 | 3 | EFM20 (AC 230–690 V) | Mounting plate | – |
| 3NP1143-1DA24 | 1 | 3 | EFM15 (AC 190–690 V) | Mounting plate | – |
| 3NP1144-1BC10 | 1 | 4 | – | Busbar | 60 mm |
| 3NP1144-1BC20 | 1 | 4 | – | Busbar | 60 mm |
| 3NP1144-1DA10 | 1 | 4 | – | Mounting plate | – |
| 3NP1144-1DA20 | 1 | 4 | – | Mounting plate | – |
| 3NP1141-1DA15 | 1 | 1 | EFM15 (DC 120–440 V) | Mounting plate | – |
| 3NP1143-1DA15 | 1 | 3 | EFM15 (DC 220–440 V) | Mounting plate | – |
Connecting sets
| Type |
|---|
| 3NP1941-1BA00 |
| 3NP1941-1BB10 |
| 3NP1941-1BB20 |
| 3NP1943-1BA00 |
| 3NP1943-1BB10 |
| 3NP1943-1BB20 |
| 3NP1943-1BG10 |
| 3NP1943-1BG30 |
| 3NP1943-1BG40 |
Accessories
| Type | Product | Size | Poles | Mounting | Busbar spacing | For |
|---|---|---|---|---|---|---|
| 3NP1940-1FA00 | Remote signalling of cover position | 1 | – | – | – | – |
| 3NP1940-1FB00 | Remote signalling of cover position | 1 | – | – | – | – |
| 3NP1941-1CA10 | Connecting space covers | 1 | 1 | Busbar | 60 mm | 1-pole design |
| 3NP1941-1CB00 | Connecting space cover | 1 | 1 | – | – | 1-pole design |
| 3NP1941-1CD00 | Connecting space covers | 1 | 1 | – | – | 1-pole design |
| 3NP1941-1EC00 | Assembly kit | 1 | 2 | Mounting plate | – | – |
| 3NP1943-1CA10 | Connecting space cover | 1 | 3 | Busbar | 60 mm | 3-pole design |
| 3NP1943-1CB00 | Connecting space cover | 1 | 3 | – | – | 3-pole design |
| 3NP1943-1CD00 | Connecting space covers | 1 | 3 | – | – | 3-pole design |
| 3NP1943-1EB00 | Mounting set | 1 | 1 | DIN rail | – | 1-pole |
| 3NP1944-1ED00 | Assembly kit | 1 | 4 | Busbar | 60 mm | – |
| 3NP1943-1DA00 | Front shield | 1 | 3 | – | – | 3-pole design |
| 3NP1943-1CF00 | Front shield | 1 | – | – | – | – |
| 3NP1900-1EF00 | Locking insert | – | – | – | – | – |
| 3NP1900-1HA00 | Locking insert | – | 3 | – | – | 3-pole design |
| 3NP1944-1MA20 | Disconnecting link | 1 | – | – | – | – |
Spare parts
| Type | Product | Size | Poles | Signalling |
|---|---|---|---|---|
| 3NP1941-1GA00 | Cover without signalling of fuse state | 1 | 1 | No |
| 3NP1941-1GB41 | Cover with fuse state indication | 1 | 1 | EFM15 (AC 110-690 V) |
| 3NP1941-1GB43 | Cover with fuse state indication | 1 | 1 | EFM15 (AC 24-230 V/DC 24-250 V (L+ L-)) |
| 3NP1941-1GB44 | Cover with fuse state indication | 1 | 1 | EFM15 (DC 120-440 V (L+ L-)) |
| 3NP1943-1GA00 | Cover without signalling of fuse state | 1 | 3 | No |
| 3NP1943-1GB10 | Cover with fuse state indication | 1 | 3 | MFM (AC 24-690 V/DC 24-240 V (L+ L-)) |
| 3NP1943-1GB20 | Cover with fuse state indication | 1 | 3 | EFM10 (AC 230-690 V) |
| 3NP1943-1GB30 | Cover with fuse state indication | 1 | 3 | EFM20 (AC 230-690 V) |
| 3NP1943-1GB42 | Cover with fuse state indication | 1 | 3 | EFM15 (AC 190-690 V) |
| 3NP1943-1GB45 | Cover with fuse state indication | 1 | 3 | EFM15 (DC 220-440 V (L+ L-)) |
| 3NP1943-1GB50 | Cover with fuse state indication | 1 | 3 | EFM25 (DC 220-440 V (L+ L-)) |
