LIMITEX rotary and cross-bar limit switches with a full stainless-steel body for corrosive environments; ATEX certified.
Full Stainless Steel Body
LIMITEX rotary and cross-bar limit switches are also available in a full stainless-steel body version alongside the standard G20 cast-iron enclosure. This version combines flameproof protection with long service life in corrosive environments — marine, offshore, chemical and food plants — and in applications requiring frequent wash-down.
The mechanical design, contact equipment and revolution-ratio / maintained-position options are the same as the cast-iron version; the ATEX certificate also covers the stainless-steel version.
- Enclosure — full stainless steel
- Types — rotary and cross-bar (position) solutions
- Certification — ATEX / IECEx, Ex d IIC T6 Gb · Ex tb IIIC T85 °C Db
- Protection — IP66 · −40 °C to +60 °C
Certifications
- Certificate — INERIS 13ATEX0020X · IECEx INE 13.0051X
- Mining — I M2 Ex d I Mb (ATEX) · Ex d I Mb (IECEx)
- Gas, Zones 1 and 2 — II 2 G Ex d IIB T6 Gb or Ex d IIC T6 Gb
- Dust, Zones 21 and 22 — II 2 D Ex tb IIIC T85 °C Db IP66
- Standards — EN / IEC 60079-0, 60079-1, 60079-31; EN 60204-1, 60204-32, 60947-1, 60947-5-1, 60529
