3NP113 Fuse Switch-Disconnectors, Size 00
Fuse switch-disconnectors for size 00 NH fuse-links, plate or busbar mounting, with EFM fuse state signalling option. This series contains 74 references.
The list is taken from OEZ's current Varius catalogue; click a type code for technical data, dimension drawings and documents on the OEZ product page. Contact us for price and stock.
Fuse switch-disconnectors
Accessories
| Type | Order code | Product | Size | Current | Poles | Mounting | Busbar spacing | For |
|---|
| 3NP1930-1FA00 | 3NP1930-1FA00 | Remote signalling of cover position | 00 | – | – | – | – | – |
|---|
| 3NP1930-1FB00 | 3NP1930-1FB00 | Remote signalling of cover position | 00 | – | – | – | – | – |
|---|
| 3NP1931-1CB00 | 3NP1931-1CB00 | Connecting space covers | 00 | – | 1 | – | – | 1-pole design |
|---|
| 3NP1931-1CD00 | 3NP1931-1CD00 | Connecting space covers | 00 | – | 1 | – | – | 1-pole design |
|---|
| 3NP1931-1EB00 | 3NP1931-1EB00 | Mounting set | 00 | – | 1 | DIN rail | – | 1-pole design |
|---|
| 3NP1931-1EC00 | 3NP1931-1EC00 | Assembly kit | 00 | – | 2 | Mounting plate | – | – |
|---|
| 3NP1931-1EE10 | 3NP1931-1EE10 | Adapter for busbar system | – | – | – | – | 60 mm | 3NP1131-1CA2. |
|---|
| 3NP1933-1CA10 | 3NP1933-1CA10 | Connecting space cover | 00 | – | 3 | Busbar | 60 mm | 3-pole design |
|---|
| 3NP1933-1CB00 | 3NP1933-1CB00 | Connecting space covers | 00 | – | 3 | – | – | 3-pole design |
|---|
| 3NP1933-1CC00 | 3NP1933-1CC00 | Connecting space covers | 00 | – | 3 | Mounting plate | – | 3-pole design |
|---|
| 3NP1933-1CD00 | 3NP1933-1CD00 | Connecting space covers | 00 | – | 3 | – | – | 3-pole design |
|---|
| 3NP1933-1EB00 | 3NP1933-1EB00 | Mounting set | 00 | – | 3 | DIN rail | – | 3-pole and 4-pole design |
|---|
| 3NP1934-1ED10 | 3NP1934-1ED10 | Assembly kit | 00 | – | 4 | Busbar | – | – |
|---|
| 3NP1934-1ED20 | 3NP1934-1ED20 | Assembly kit | 00 | – | 2 | Busbar | – | – |
|---|
| 3NP1933-1DA00 | 3NP1933-1DA00 | Front shield | 00 | – | 3 | – | – | 3-pole design |
|---|
| 3NP1933-1CF00 | 3NP1933-1CF00 | Front shield | 00 | – | – | – | – | – |
|---|
| 3NP1900-1EF00 | 3NP1900-1EF00 | Locking insert | – | – | – | – | – | – |
|---|
| 3NP1900-1HA00 | 3NP1900-1HA00 | Locking insert | – | – | 3 | – | – | 3-pole design |
|---|
| 3NP1934-1MA20 | 3NP1934-1MA20 | Disconnecting link | 00 | – | – | – | – | – |
|---|
| ZP000 | OEZ:06401 | Disconnecting link | 000 | 160 A | – | – | – | 000 |
|---|
Spare parts
| Type | Product | Size | Poles | Signalling |
|---|
| 3NP1931-1GA00 | Cover without signalling of fuse state | 00 | 1 | No |
|---|
| 3NP1931-1GB41 | Cover with fuse state indication | 00 | 1 | EFM15 (AC 110-690 V) |
|---|
| 3NP1931-1GB43 | Cover with fuse state indication | 00 | 1 | EFM15 (AC 24-230 V/DC 24-250 V (L+ L-)) |
|---|
| 3NP1931-1GB44 | Cover with fuse state indication | 00 | 1 | EFM15 (DC 120-440 V (L+ L-)) |
|---|
| 3NP1933-1GA00 | Cover without signalling of fuse state | 00 | 3 | No |
|---|
| 3NP1933-1GB10 | Cover with fuse state indication | 00 | 3 | MFM (AC 24-690 V/DC 24-240 V (L+ L-)) |
|---|
| 3NP1933-1GB20 | Cover with fuse state indication | 00 | 3 | EFM10 (AC 230-690 V) |
|---|
| 3NP1933-1GB30 | Cover with fuse state indication | 00 | 3 | EFM20 (AC 230-690 V) |
|---|
| 3NP1933-1GB42 | Cover with fuse state indication | 00 | 3 | EFM15 (AC 190-690 V) |
|---|
| 3NP1933-1GB45 | Cover with fuse state indication | 00 | 3 | EFM15 (DC 220-440 V (L+ L-)) |
|---|
| 3NP1933-1GB50 | Cover with fuse state indication | 00 | 3 | EFM25 (DC 220-440 V (L+ L-)) |
|---|
